SUN-8K-SG05LP3-EU

Hibridni

Šifra: SUN-8K-SG05LP3-EU

Isporuka 10 dana
Proizvod je dostupan kroz 10 dana

Samo za registrirane korisnike

Registrirajte se za prikaz ili kupnju proizvoda

Prijava

Max. snaga: 12800 W
Raspon napona baterije: 40-60 V
Max. struja punjenja/pražnjenja:37 A


Certifikati (klikni za pregled i preuzimanje):



    Battery Input Data

  • Battery Type: Li-ion
  • Battery Voltage Range: 160–700 V
  • Max. Charging Current: 37 A
  • Max. Discharging Current: 37 A
  • Charging Strategy for Li-ion Battery: Self-adaption to BMS

    • PV String Input Data

  • Max. DC Input Power: 12.800 W
  • Max. DC Input Voltage: 1.000 V
  • Start-up Voltage: 180 V
  • MPPT Voltage Range: 150–850 V
  • Rated DC Input Voltage: 600 V
  • Max. Operating PV Input Current: 20 + 20 A
  • Max. Input Short-Circuit Current: 30 + 30 A
  • No. of MPP Trackers: 2
  • No. of Strings per MPP Tracker: 1 + 1

    • AC Output Data

  • Rated AC Active Output Power: 8.000 W
  • Max. AC Output Active Power: 8.800 W
  • Max. AC Output Apparent Power: 8.800 VA
  • Rated AC Output Current: 12,2 / 11,6 A
  • Max. AC Output Current: 13,4 / 12,8 A
  • Nominal Output Voltage/Range: 220/380 V, 230/400 V
  • Grid Connection: 3L/N/PE
  • Rated Grid Frequency: 50/60 Hz
  • Power Factor Adjustment Range: 0.8 leading – 0.8 lagging
  • Total Harmonic Distortion (THDi): <3%

    • Efficiency

  • Max. Efficiency: 97,6%
  • Euro Efficiency: 97,0%
  • MPPT Efficiency: >99%

    • General Data

  • Operating Temperature Range: -40 to +60 °C
  • Cooling: Smart Cooling
  • Noise: <55 dB
  • Communication: RS485 / RS232 / CAN
  • Protection Degree: IP65
  • Installation Style: Wall-mounted
